Ubiquiti USW-Pro-Max-16-PoE, 16-Port PoE Switch

Κωδικός προϊόντος: USW-Pro-Max-16-PoE

Ubiquiti USW-Pro-Max-16-PoE, 16-Port PoE Switch

Etherlighting™ ports that illuminate to indicate port location, speed/link, and native VLAN/network
(4) 2.5 GbE PoE++ ports
(12) GbE PoE+ ports
(2) 10G SFP+ ports
180W total PoE availability
Versatile desktop, wall, and rack mounting
Silent, fanless cooling system

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

$45,756.00

Διαθέσιμο κατόπιν παραγγελίας

11 People watching this product now!

To pick up today

Our courier will deliver to the specified address

2-3 Days

DHL courier will deliver to the specified address

2-3 Days

Payment Methods:

Performance
Switching Capacity	84 Gbps
Total Non-Blocking Throughput	42 Gbps
Forwarding Rate	62 Mpps
Supported VLANs	1,000
MAC Address Table Size	16,000
L3 Table Size	ARP Entries: 6,000 \| IPv4 Routes: 512
Packet Buffer Size	1.5 MB

Layer 3 Features
DHCP Server (Local Networks)	Yes
DHCP Relay	Yes
Inter-VLAN Routing (Local Networks)	Yes
Static Routing (Local Networks)	Yes

Layer 2 Features
LACP Port Aggregation	Yes
STP & RSTP	Yes
QoS (DSCP)	Yes
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)	Yes
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)	Yes
IGMP Snooping	Yes
802.1X Control	Yes
MAC-Based ACLs & Device Isolation	Yes
DHCP Snooping & Guarding	Yes
Egress Rate Limit	Yes
Flow Control	Yes
Storm Control	Yes
Multicast & Broadcast Rate Limiting	Yes
MAC Address Blocking	Yes
IP-Based ACLs & Network Isolation	Yes
MAC-Based Port Restriction	Yes
Port Isolation	Yes
Port Mirroring	Yes
Jumbo Frames	Yes
LLDP-MED	Yes
Voice VLAN	Yes
Loop Protection	Yes

Hardware
PoE Ports	PoE+: 12 \| PoE++: 4
Max. PoE Wattage per Port by PSE	PoE 15.4W \| PoE+ 32W \| PoE++ 64W
Max. Power Consumption	25W (Excluding PoE Output) 210W (Including PoE Output)
Power Method	AC Adapter
Power Input Method	AC input
Power Supply	AC/DC, external, 210W
Supported Voltage Range	50—54V DC
Management	Ethernet AR
Heat Dissipation (Excluding PoE Output)	102.36 BTU/hr
Weight	2.1 kg (4.6 lb)
Enclosure Material	SGCC steel
Mount Material	SGCC steel
Supported Rack Depth	400~1200 mm (15.7-47.2″)
LCM Display	1.3″ touchscreen
Ambient Operating Temperature	-5 to 40° C (23 to 104° F)
Ambient Operating Humidity	10 to 90% noncondensing
Etherlighting™	Ethernet: Yes \| SFP+: Yes
Certifications	CE, FCC, IC
NDAA Compliant	Yes
